AUTODESK AUTOCAD DESIGN & DRAFTING COURSE

Duration: 1.5 - 2 Months (50 Hours) Mode: Classroom & Live Online Eligibility: All Engineering Branches, Diploma & ITI Certification: Industry Standard Drafting Credential

Course Overview

Autodesk AutoCAD is the essential foundation for engineering design and technical drafting worldwide. The AutoCAD course at TMD Infra is specially designed to bridge basic CAD skills with high-precision MEP, architectural, and structural drawing creation.

From basic geometry and coordinate systems to advanced layer management, dynamic blocks with attributes, external reference (Xref) overlaying, isometric schematics, and scaled layout plotting to PDF/DWG, students acquire the speed and accuracy expected by global EPC consultancies.

What You Will Learn

2D Precision Drafting

Polylines, arcs, splines, snaps, coordinates & modify tools.

Dynamic Blocks & Xrefs

Parametric blocks, attributes, title blocks & external references.

Layers & Standards

AIA / ISO layer naming, lineweights, color palettes & filters.

Plotting & Sheet Layouts

Paper space viewports, scale factors, CTB plot styles & publishing.

Complete Syllabus & Modules

  • AutoCAD interface, application menu, status bar & command line efficiency
  • Drawing limits, units (Architectural, Engineering, Decimal, Metric)
  • Coordinate systems: Absolute, Relative Rectangular & Relative Polar
  • Navigation tools: Pan, Zoom Realtime, Zoom Window & Navigation Bar
  • Lines, Polylines, Circles, Arcs, Ellipses, Rectangles & Polygons
  • Object Snaps (OSNAP), Object Snap Tracking (OTRACK), Ortho & Polar Tracking
  • Hatch patterns, gradients & boundary creation
  • Move, Copy, Rotate, Scale, Stretch, Mirror & Array (Rectangular / Polar)
  • Trim, Extend, Fillet, Chamfer, Break, Join & Offset commands
  • Grip editing, quick properties & Match Properties (MATCHPROP)
  • Layer creation, color assignment, linetypes & lineweights
  • Layer states: On/Off, Freeze/Thaw, Lock/Unlock & Viewport Freezing
  • Layer filters & layer standards conforming to MEP disciplines
  • Single-line & Multi-line text styles with annotative scaling
  • Linear, Aligned, Angular, Radius, Diameter & Baseline dimensioning
  • Multi-leaders (MLEADER) & schedule table creation
  • Block creation (BLOCK & WBLOCK), insert points & symbol libraries
  • Dynamic blocks: Visibility states, stretch actions & rotation parameters
  • Block attributes for title blocks & equipment tag extraction
  • Attaching & overlaying External References (Xrefs) & clipping boundaries
  • Model Space vs. Paper Space layout configuration
  • Setting up standard sheet sizes (A0, A1, A2, A3, A4) with title blocks
  • Scaled viewports, viewport lock & annotation scale synchronization
  • Plot style tables (monochrome.ctb / color-dependent) & batch plotting to PDF

Target Career Opportunities

  • AutoCAD MEP Draftsman
  • Architectural / Civil CAD Technician
  • Shop Drawing Specialist
  • Electrical / Piping CAD Modeler
  • Engineering Documentation Executive
