Power & Low Voltage (ELV) Systems

ELECTRICAL DESIGN & DRAFTING COURSE

Duration: 2 - 3 Months (75 Hours) Mode: Classroom & Live Online Eligibility: Electrical / EEE Engineers & Diploma Certification: NEC, NBC & IEEE Standards

Course Overview

The Electrical Design Course at TMD Infra prepares engineers for high-growth roles in power distribution, substation engineering, building electrification, and Extra Low Voltage (ELV) systems.

The curriculum adheres to the National Electrical Code of India (NEC), Indian Electricity Rules (IE Rules), NBC 2016, and IEEE/IEC guidelines. Learners gain mastery over connected load schedules, diversity factors, transformer & diesel generator (DG) sizing, fault level short-circuit calculations, voltage drop, cable tray sizing, capacitor power factor correction, earthing, lightning protection, DIALux lighting lux simulations, and Single Line Diagram (SLD) preparation.

What You Will Learn

Substation & Transformer

HT/LT switchgear, transformer sizing & DG synchronization.

DIALux Lighting Design

Lux calculations, luminaire selection & energy compliance.

Cable & Tray Sizing

Derating factors, voltage drop & short circuit fault levels.

Earthing & Lightning (IS 3043)

Chemical earthing pits, touch/step voltage & ESE arrestors.

Complete Syllabus & Modules

Module 1: General Concepts, Electrical Codes & Standards

Role of Electrical Design Engineer in MEP Projects
Indian Electricity (IE) Rules & State Electricity Regulatory Commission norms
National Electrical Code (NEC), National Building Code (NBC 2016 Part 8)
Bureau of Indian Standards (BIS) & IEEE / IEC standards
Pollution Control Board statutory requirements for DG Noise & Emissions

Module 2: Electrical Equipment, Switchgear & Applications

Circuit Protection: MCB, MCCB, ACB, VCB, ELCB/RCCB and relay coordination
Transformers: Oil-filled vs. Dry Cast Resin, impedance & vector groups
Diesel Generators (DG Sets): Standby, Prime & AMF panel synchronization
Capacitor Banks (APFC Panels) for Power Factor correction (cos phi ≥ 0.98)
Bus Ducts (Sandwich type) vs. Cable risers in high-rise buildings
UPS & Centralized Inverters, Battery Banks sizing for emergency loads

Module 3: Power Distribution Architecture & Containment

Main LT Panels, PCC (Power Control Center), MCC (Motor Control Center)
Sub-Distribution Boards (SDB) & Final Distribution Boards (DB)
Cable tray selection: Perforated, Ladder & Wire Mesh trays with space calculation
Raceways, PVC/GI conduit containment & underground trench routing

Module 4: Building Electrical Load Scheduling

Internal & external lighting wattage estimations
Raw power vs. Clean UPS power for IT / Data Centers
HVAC mechanical loads (Chillers, AHUs, FCUs, Fans)
PHE & Fire Fighting pumping motor starting current calculations
Elevator / Lift motorized load and regenerative power

Module 5: Core Engineering Design Calculations

Maximum Peak Demand Calculation with Diversity Factors
Transformer kVA Sizing & Percentage Impedance (%Z)
Diesel Generator kVA / kW sizing with Step Loading
Short-Circuit fault level calculation (kA) at various panel tiers
Cable Sizing based on Continuous Current, Derating & % Voltage Drop
Earthing calculation (IS 3043 / IEEE 80) & Earth conductor sizing
Lightning Protection Risk Assessment as per IS/IEC 62305

Module 6: Single Line Diagram (SLD) & CAD Layouts

Preparation of Overall Electrical Single Line Schematic (SLD) with Metering & Interlocking
Lighting, Raw Power & UPS Small Power CAD floor plan layouts
Substation & DG Room detailed layout with clearances
Cable Tray, Earthing Grid & Lightning Protection shop drawings
Bill of Quantities (BOQ) & Technical Equipment Specifications
